Black Leopard E Series LED Emergency Lighting

Black Leopard E Series LED Emergency Lighting

●Osram led source, high lumen output over 120lm/W.

●Modular design,available in 240W to 960W.

●Aviation aluminum, thermal conductivity is 1.8 times of die-casting AL.

●Shock and vibration resistant.

●Own design and produced LED drivers are provide reliable operation in harsh environments.

●Capable to work on extreme high and low temperature -45℃-+60℃ ,keep good performance.

●IP66 and high corrosion resistance,can be used in ocean environment.

●Lightning protection 6KV, THD≤5%.

￥ 0.00
0.00


●Osram led source, high lumen output over 120lm/W.

●Modular design,available in 240W to 960W.

●Aviation aluminum, thermal conductivity is 1.8 times of die-casting AL.

●Shock and vibration resistant.

●Own design and produced LED drivers are provide reliable operation in harsh environments.

●Capable to work on extreme high and low temperature -45℃-+60℃ ,keep good performance.

●IP66 and high corrosion resistance,can be used in ocean environment.

●Lightning protection 6KV, THD≤5%.

Power consumption160W200W240W360W480W720W960W
  Item No.BBL160/
    BBL160-E		BBL200/
    BBL200-E		BBL240/
    BBL240-E		BBL360/
    BBL360-E		BBL480/
    BBL480-E		BBL720/
    BBL720-E		BBL960/
    BBL960-E
  Input   voltage&frequencyAC   100-277V
    47-62Hz		AC   100-277V
    47-62Hz		AC   100-277V
    47-62Hz		AC   100-277V
    47-62Hz		AC   100-277V
    47-62Hz		AC   100-277V
    47-62Hz		AC   100-277V
    47-62Hz
  Input current860～2400mA860～2400mA860～2400mA1300～3600mA1730～4800mA2600～7200mA3460～9600mA
  Power factor (PF)≥0.98≥0.98≥0.98≥0.98≥0.98≥0.98≥0.98
  LED chipsOSRAM   or Other efficientOSRAM   or Other efficientOSRAM   or Other efficientOSRAM   or Other efficientOSRAM   or Other efficientOSRAM   or Other efficientOSRAM   or Other efficient
  Luminous Flux19200lm24000lm28800lm43200lm57600lm86400lm115200lm
  DImensions(mm)362*132*343mm362*132*343mm362*132*343mm362*132*475mm362*132*597mm(A)
    649*133*343mm(B)		649*133*475mm649*133*597mm
  Weight6.0kg6.0kg6.0kg8.2kg10.0kg13.5kg17.5kg
  Colour rendering   index
      (CRI)		Ra   > 80
  Colour temperatureWW:2800～3300K              PW:4700～5400K           CW:5700～7100K
  Beam angle20°/40°/60°/90°/140°
  Working ambient temp.-45℃～+60℃
  IP GradeIP66
  Lifspan≥50000hrs
  HousingCopper-free   aluminum
  Front CoverPolycarbonate
  L70≥50000   hrs
